Horsepower & Torque: 830 Horsepower / 800 ft. lbs. Torque
Cylinder Heads: BluePrint Engines LS3 Aluminum Cylinder Heads
Compression Ratio: 9.5:1
Camshaft: Hydraulic Roller Cam - .624 Intake / .624 Exhaust Lift and 239 Intake / 255 Exhaust Duration @ .050 - 114° LSA - Three Bolt Cam
Pistons: Forged
Crankshaft: Forged Crank - 4.125" Stroke and 6.125" Rods
Supercharger: Magnuson TVS2650
Fuel Recommendation: 91+ Octane
This engine Does NOT come with a Fuel Injection ECU and Wiring Harness.
- Description
- Engine Specs
- Parts & Accessories
- Warranty
Overview:
Description:
- Horsepower & Torque: 830 Horsepower / 800 ft. lbs. Torque
- Compression Ratio: 9.5:1
- BluePrint Engines LS3 Aluminum Heads
- BluePrint Engines Hydraulic Roller Cam
- BluePrint Engines Forged Crank
- BluePrint Engines Forged Pistons
Block:
- BluePrint Engines High Strength Cast Iron Block
- Increased Deck Thickness and Strength Webbing
- Utilizes OEM LS3 Front and Rear Covers
- Improved Water Jacket Design
- Extended Cylinder Skirt
- 1-Piece Rear Main Seal
- Priority Main Oiling
- 4.070" Bore
- 6-Bolt Main
Rotating Assembly:
- Forged Crankshaft
- 4.125" Stroke
- Forged 6.125" Connecting Rods
- Forged Pistons
- Internally Balanced Front and Rear
Cylinder Heads:
- BluePrint Aluminum Cylinder Heads - PS8015
- 70cc Chamber
- 2.165" Intake / 1.600" Exhaust Valves
- 259cc Intake / 102cc Exhaust Runners
Cam Specs:
- Hydraulic Roller
- .624 Intake / .624 Exhaust Lift
- 239 Intake / 255 Exhaust Duration
- @.050-114 Degree Lobe Separation
Also Includes:
- Low Profile Rear Sump Oil Pan - BPP81074
- All Sensors Required for Engine to Run
- DBW Throttle Body - BPP12191019
- Magnuson TVS2650 Supercharger
- Spark Plugs & Wires
- Harmonic Balancer
- Timing Cover
- Valve Covers
- Coil Packs
Notes:
- Not for use in pollution-controlled vehicles.
Blocks
- BluePrint Engines High Strength Cast Iron Block
- Increased Deck Thickness and Strength Webbing
- Utilizes OEM LS3 Front and Rear Covers
- Improved Water Jacket Design
- Extended Cylinder Skirt
- 1-Piece Rear Main Seal
- Priority Main Oiling
- 4.070" Bore
- 6-Bolt Main
Cylinder Heads
- BluePrint Aluminum Cylinder Heads - PS8015
- 70cc Chamber
- 2.165" Intake / 1.600" Exhaust Valves
- 259cc Intake / 102cc Exhaust Runners
Ignition Timing
ECM Supplied with Calibration
Spark Plug
.030 in.
Firing Order
1,8,7,2,6,5,4,3
Rotating Assembly
Forged Crank - 4.125 in. Stroke and Forged 6.125 in. Rods
Cam Specs
Hydraulic Roller - .624 Intake / .624 Exhaust Lift - 239 Intake / 255 Exhaust Duration -@.050-114 LSA
Stall Converter
2200+ RPM
Also Includes
- Low Profile Rear Sump Oil Pan - BPP81074
- All Sensors Required for Engine to Run
- DBW Throttle Body - BPP12191019
- Magnuson TVS2650 Supercharger
- Spark Plugs & Wires
- Harmonic Balancer
- Timing Cover
- Valve Covers
- Coil Packs
Notes
- Not for use in pollution-controlled vehicles.
Your BluePrint engine was dyno tested with the parts and specifications listed below. If you prefer to install a different part, your engine may not produce the horsepower recorded on your dyno sheet.
Parts & Accessories Specs
| Intake Manifold | TVS2650 Supercharger |
|---|---|
| Spark Plug | NGK 3689 (TR6IX) |
| Harmonic Balancer | Non-Weighted |
| Flexplate/Flywheel (Not Included) | Non Weighted BPP12654640 - BPPLS1611 |
| Fuel Recommendation | 91+ Octane |
| Recommended Service Oil | BPPB160 |
| Recommended Oil Filter | 6 Quarts |
Header Partners:
- Click Here for our Header Partners and recommendations.
Better Than the Rest.
The satisfaction of our customers is our highest priority at BluePrint Engines. Every engine we build is assembled with premium components, balanced to within two grams, and dyno-tested to verify real horsepower and torque before it leaves our facility.
All BluePrint products include warranty protection designed specifically for how they're used. Our complete crate engines carry our industry-leading 30-month / 50,000-mile warranty, offering the confidence and peace of mind serious builders expect. Other BluePrint products—including bare blocks, marine engines, transmissions, race applications, and cylinder heads—feature warranty coverage tailored to their intended use and operating conditions.
For full terms and specific coverage by product category, download our warranty guide below. It contains complete details, limitations, and instructions for warranty registration and claims.
Already Own this engine?
Protect your investment by registering your warranty today. Register below to ensure coverage and stay up to date on important service information.
Register NowEVERY BLUEPRINT ENGINE ACES THE DYNO TEST
We make sure we hit our target horsepower and proper torque with every crate engine. We use an advanced computerized balancer in our in-house dyno testing rooms to get our rotating assemblies within two grams, ensuring silky smooth power over the entire RPM range. That’s precisely why our engines sound and run better than our competitors.
All specs, zero speculation: A comprehensive, dyno-generated printout showing your critical engine specs will accompany your delivered engine — every time. No more guessing or wondering what your installed engine’s real-world peak horsepower and torque ratings actually are. Any doubters in the crowd? Simply flash ‘em your exact engine’s dyno results.
